Hemorrhage Detected Using MR Imaging in the Setting of Acute Stroke: An In Vivo Model

The treatment algorithm for acute cerebrovascular accidents has traditionally sorted patients on the basis of nonhemorrhagic or hemorrhagic conditions as determined by findings on emergency CT studies (1–6). The recent Food and Drug Administration (FDA) approval and clinical application of thrombolytic therapy for acute stroke has reemphasized this important distinction, as well as highlighted the need for rapid diagnosis and treatment (7). While additional information (the level of vascular occlusion, viability, and volume of brain at risk) is critical in advancing acute stroke therapy, the time expended acquiring these CT data will delay treatment and possibly exacerbate the injury. MR imaging, with its ability to allow expeditious assessment of the vascular substrate and to acquire dynamic studies of regional blood volume, coupled with diffusion techniques and parenchymal imaging, make it particularly amenable to this application (8, 9). As alternative treatments become available (eg, intra-arterial thrombolysis), efficient and accurate triage of selected patients for particular therapies will require such ancillary data (10).

Nevertheless, the sensitivity of MR imaging for the detection of acute intra- and extra-axial blood during the narrow therapeutic window remains paramount and is still open to question. To date, this issue has been addressed by retrospective analyses of studies in patients presenting with acute focal deficits, only a fraction of whom were evaluated within the therapeutic window and none of whom were administered thrombolytics on the basis of the MR studies alone (11–13). The purpose of this study was to investigate the combined sensitivity and specificity of conventional spin-echo (SE) T1-weighted, spin-density (SD)–weighted, T2/T2*-weighted gradient-echo (GRE), and fluid-attenuated inversion-recovery (FLAIR) MR sequences to small amounts of parenchymal and subarachnoid hemorrhage (SAH) during the first 6 hours in an in vivo animal model.

Methods

Eighteen mongrel dogs were examined: 12 with iatrogenic SAH, six with parenchymal hematomas in one or both hemispheres, and three with both. Animal Care Committee approval was obtained before the start of the investigation.

Anesthesia induction was with thiopental 20 mg/kg IV (50 mg/mL concentration) to effect. The parenchymal hemorrhage was created by injecting fresh arterial autologous blood (1 mL) into the brain parenchyma through a burr hole using a 22-gauge spinal needle. SAH was created by injecting 2 mL of arterial blood mixed with 2 mL of autologous CSF with a 22-gauge spinal needle inserted into the subarachnoid space through a cisternal puncture. The volume of iatrogenically introduced blood was intentionally small so as to minimize anatomic distention due to gross mass effect. The animals were euthanized at the completion of the 6-hour imaging protocol. Postmortem examination was performed in each animal to confirm the location(s) of the iatrogenic hemorrhage.

MR imaging was performed with a 1.5-T whole-body unit. The animals were imaged in the supine position using a clinical transmit/receive head coil at the following intervals: before hemorrhage (baseline), immediately after ictus, and at 1, 2, 4, and 5½ hours after ictus. Each MR study was completed within a half hour and consisted of a conventional T1-weighted SE sequence, a conventional double-echo SD/T2-weighted SE sequence, a fast FLAIR sequence, and a T2*-weighted GRE sequence. Contiguous axial images were acquired in an interleaved fashion using acquisition parameters similar to those used in human clinical protocols (see Table 1). A noncontrast CT study was also performed 3 hours after ictus with the following parameters: 5-mm section thickness, 140 Kv, 274 to 360 mA, 1.5-second scan cycle, 140-mm field of view, and 512 × 512 matrix.

All 108 MR examinations were interpreted in a random fashion by two neuroradiologists who were blinded to the animal's identity, the presence or absence of intervention, and the time the scan was acquired relative to iatrogenic ictus. The location, size, and signal of all imaging abnormalities and the diagnosis (presence or absence of blood) were recorded, as was the contribution of each MR pulse sequence to the interpretation in view of the expected findings predicted from prior retrospective studies (11, 14–16). More specifically, parenchymal hemorrhage was expected as a heterogeneous mass with a ringlike area of low signal intensity relative to adjacent brain parenchyma on both T1- and T2-weighted images, possibly with a surrounding area of high signal edema on T2-weighted studies. Arterial SAH was expected to be higher in signal intensity than CSF on T1-weighted SE and GRE images as well as on SD and FLAIR sequences, but lower in signal intensity relative to CSF on T2-weighted images. This may be regarded as a complete or partial reversal of the expected CSF/parenchymal contrast that often results in blurring of the CSF/brain interface.

The interpreters assessed each image with respect to parenchymal hemorrhage and SAH, and expressed their confidence in each diagnosis as a percentage (0% to 100%). These data were subsequently analyzed in terms of diagnostic accuracy by measuring the area under the receiver operating characteristic (ROC) curve. Nonparametric estimates of the ROC area were computed (17). To estimate the ROC area for parenchymal hemorrhage, a hemisphere rather than a subject was considered the unit of observation, as with SAH. In computing the ROC area for parenchymal hemorrhage, we compared hemispheres with parenchymal hemorrhage to hemispheres without parenchymal hemorrhage (including SAH). Similarly, in computing the ROC area for SAH, we compared animals with SAH to animals without SAH (including animals with parenchymal hemorrhage). To accommodate the correlation of parenchymal hemorrhage test results between hemispheres within a subject, we applied a nonparametric analysis for clustered ROC curve data (18). For all analyses, we used a significance level of .05 (ie, 95% CI). Individual pulse sequences were rated as to their contribution to each diagnosis (in addition to the above-described diagnostic accuracy confidence ratings). Data on the contribution of each MR imaging sequence to the detection and diagnosis were analyzed by Friedman's χ²-test.

The area under the ROC curve was interpreted as the probability that a randomly chosen subject with SAH (or random hemisphere with parenchymal hemorrhage) would be scored with greater suspicion than would a randomly chosen subject (or hemisphere) without SAH (or parenchymal hemorrhage). If MR imaging has no ability to show the distinction between SAH (or parenchymal hemorrhage) and a non-SAH (or nonparenchymal hemorrhage), then the ROC area would theoretically be 0.5. If the CI for the true ROC area contains 0.5, then there is insufficient evidence that the diagnostic technique in question is any better than, for example, a coin flip. In addition, the diagnostic accuracies of MR imaging and CT in the detection of SAH were statistically compared via the z-test. A similar comparison between MR imaging and CT for parenchymal hemorrhage was also performed.

CT scans were interpreted blindly in the usual fashion; blood proteins were expected to appear as an area of high-attenuation coefficient in the subarachnoid space or brain parenchyma, depending on the location of the hemorrhage (19–21). As with the interpretation of the MR studies, interpretations of the3-hour CT scans were subjected to the same ROC analysis (17, 18).

Results

Postmortem examination confirmed the presence of parenchymal hemorrhage or SAH or both in each subject. Tables 1 and 2 summarize, by reader, the results of the diagnostic accuracy of the MR study. Several studies were interrupted because of inadequate anesthesia or subject motion (hence, the variability of n at each time point). In Table 1, estimates of diagnostic accuracy for detecting SAH are given; Table 2 shows estimates of diagnostic accuracy for detecting parenchymal hemorrhage. The results are summarized at each time point and then pooled to produce an overall estimate of diagnostic accuracy within the therapeutic window. In addition to the estimates of diagnostic accuracy, the tables also give the number of observations at each time point, the number of observations in which the reader indicated some (ie, >0%) confidence in the presence of SAH (Table 1) or parenchymal hemorrhage (Table 2), and the average confidence score for those cases.

In Table 1, for reader 1 at baseline, two subjects have SAH and 16 do not. In the two subjects with SAH, the reader did not detect (at any confidence level) the SAH, so there are no true-positive scores out of a possible two. In the 16 cases without SAH, the reader assigned some confidence to the presence of SAH in three cases (average confidence score, 60.0). Thus, at baseline, the 95% CI for the ROC area for reader 1 does contain 0.5, and the 95% CI for reader 2 is completely below 0.5. Note that (for either reader) the 95% CI for time points 0 hour, 1 hour, 2 hours, 4 hours, and 6 hours do not contain 0.5. Therefore, for these time points, MR imaging is significantly better than chance for predicting the presence of SAH.

The overall estimate of diagnostic accuracy for detecting SAH (excluding baseline) was 0.86 for reader 1 (95% CI, 0.76–0.97) and 0.85 for reader 2 (95% CI, 0.71–0.99). In other words, we are 95% confident that reader 1 is able to distinguish SAH from non-SAH 76% to 97% of the time, and that reader 2 is able to make this distinction 71% to 99% of the time. For each reader, we also tested whether the diagnostic accuracy at the 0-hour time point differed from the diagnostic accuracy at the 6-hour time point. The differences were not statistically significant at the .05 level (reader 1: P = .07; reader 2: P = 1.00).

In Table 2, the diagnostic accuracy for detecting parenchymal hemorrhage at baseline could not be estimated, since there were no hemispheres with parenchymal hemorrhage. After baseline, all the ROC areas could be estimated; neither of the 95% CIs for the two readers contained 0.5, indicting that MR imaging is better than chance for predicting presence or absence of parenchymal hemorrhage. Also, as with the SAH data, the results were pooled across the five time points for each reader to arrive at an overall estimate of diagnostic accuracy for detecting parenchymal hemorrhage. Excluding baseline, this was 0.90 for reader 1 (95% CI, 0.81–0.99) and 0.93 for reader 2 (95% CI, 0.84–1.00). In other words, we are 95% confident that reader 1 is able to distinguish parenchymal from nonparenchymal hemorrhage 81% to 99% of the time, and that reader 2 is able to make this distinction 84% to 100% of the time. For each reader, we also tested the diagnostic accuracy at the 0-hour time point against that at the 6-hour time point. The differences in diagnostic accuracy were not statistically significant (reader 1: P = .19; reader 2: P = .18).

Also measured were the relative contributions of each scan/pulse sequence to the diagnosis of SAH and parenchymal hemorrhage (Figs 1 and 2, respectively). With SAH, lesion detection was much better with fast FLAIR, but the conventional SD-weighted SE and T2*-weighted GRE sequences were also important in establishing the hemorrhagic diagnosis (Fig 1). For the SAH studies, the conventional T1- and T2-weighted SE images frequently failed to provide any useful information for detection or diagnosis. Parenchymal hemorrhage was identified in every canine at least at one time point by MR imaging. In the case of parenchymal hemorrhage, the T2*-weighted GRE sequences were most helpful for the detection and diagnosis of lesions (Fig 2). For the detection of lesions, the fast FLAIR images were the second most helpful, but for diagnosis, the T2-weighted SE images were the second most helpful. Conversely, the conventional T1- and SD-weighted SE images were found not to be beneficial in the evaluation of parenchymal hemorrhage. These findings were consistent, independent of the time at which the images were acquired relative to the time of hemorrhage creation. An example of false-negative detection appears in Figure 3.

• Download figure
• Open in new tab
• Download powerpoint

fig 1.

A–F, T1-weighted (A), SD-weighted (B), T2-weighted (C), FLAIR (D), and GRE (E) MR images and CT scan (F) of SAH at the level of the cervicomedullary junction in the same canine. Blood is seen on the MR images (obtained 2 hours after ictus) as an area of high signal obscuring the CSF-brain interface on the left (arrows). This is most conspicuous on the FLAIR image (D) and is not seen to any significant degree on the T2-weighted image (C) or the CT scan (F), performed 1 hour later.

• Download figure
• Open in new tab
• Download powerpoint

fig 2.

A–F, T1-weighted (A), SD-weighted (B), T2-weighted (C), FLAIR (D), and GRE (E) MR images and CT scan (F) of parenchymal hemorrhage within the right hemisphere in the same canine. All MR studies were performed 2 hours after ictus and show a focus of low-signal susceptibility artifact near the vertex, which, on the 3-hour CT scan, is found to be iatrogenically introduced gas (arrow). The T1-weighted image (A) does not show the parenchymal hemorrhage, whereas the SD-weighted image shows only vague loss of the gray/white junction (arrowhead, B). T2-weighted (C) and FLAIR (D) images display the heterogeneous hematoma with a ring of low signal (arrowhead) surrounded by vasogenic edema (open arrow). GRE image (E) prominently shows only heterogeneous susceptibility effect in the area of the hematoma (arrowhead), while CT scan shows the typical high-attenuation mass (F).

• Download figure
• Open in new tab
• Download powerpoint

fig 3.

Hyperacute parenchymal hemorrhage.

A–C, T1-weighted (A), T2-weighted (B), and FLAIR (C) MR images obtained immediately after creation of parenchymal hemorrhage show a false-negative abnormality not detected by either reader.

D–F, T1-weighted (D), T2-weighted (E), and FLAIR (F) MR images in the same animal 1 hour after creation of the hemorrhage show the obvious abnormality in the area of the corpus callosum, consistent with hyperacute parenchymal hemorrhage. All abnormalities were detected by both readers on all sequences.

Tables 3 and 4 summarize the results of the diagnostic accuracy aspect of the CT studies obtained by readers 1 and 2. In Table 3, the estimates of diagnostic accuracy for detecting SAH are given; Table 4 shows the estimates of diagnostic accuracy for detecting parenchymal hemorrhage. The overall estimate of diagnostic accuracy for detecting SAH was 0.42 for reader 1 (95% CI, 0.26–0.58) and 0.66 for reader 2 (95% CI, 0.43–0.89). Hence, we are 95% confident that reader 1 is able to distinguish SAH from non-SAH 26% to 58% of the time, and that reader 2 is able to make this distinction 43% to 89% of the time (Fig 1). Note that (for both readers) the 95% CIs contain 0.5. Thus, in this instance, there is no evidence that CT was useful (ie, significantly better than guessing) in distinguishing non-SAH from SAH in this animal model.

For reader 1, the difference in accuracy between MR imaging (0.79) and CT (0.42) in detecting SAH was statistically significant (P < .001, z-test). However, for reader 2, the difference in accuracy between MR imaging and CT (0.84 versus 0.66) in detecting SAH was not statistically significant (P = .12, z-test).

Table 4 shows the diagnostic accuracy of CT for detecting parenchymal hemorrhage. For both readers, the 95% CIs do not contain 0.5; thus, CT is significantly better than guessing for predicting the presence or absence of parenchymal hemorrhage. The overall estimate of diagnostic accuracy for detecting parenchymal hemorrhage was 0.91 for reader 1 (95% CI, 0.85–0.97) and 0.76 for reader 2 (95% CI, 0.69–0.83) (Fig 2).

For reader 1, the difference between MR imaging (0.90) and CT (0.91) in detecting parenchymal hemorrhage was not statistically significant (P = .74, z-test); for reader 2, the difference between MR imaging (0.93) and CT (0.76) was significant (P < .001, z-test).

Discussion

In 1995, the rt-PA Study Group of the National Institute of Neurologic Disorders and Stroke (NINDS) reported improved outcomes at 90 days in patients with presumed ischemic stroke treated with intravenous rt-PA within 3 hours of the onset of symptoms. On the basis of these findings, the FDA subsequently approved the use of rt-PA for the treatment of acute stroke (7). Because of the3-hour time-to-treat constraint imposed by the study protocol, pretreatment imaging was limited to CT in order to exclude patients with a possible hemorrhagic component to their neurologic deficit. Conversely, this and previous work suggest that additional diagnostic information (eg, the site and size of vessel occlusion, the extent of infarction, and the residual viability of adjacent brain parenchyma) may be helpful in optimizing present treatment regimens and in defining those of the future (10, 22–25). In this context, interest has been directed toward considering the feasibility of a single expeditious diagnostic examination. MR imaging and dynamic spiral CT scanning have both been proposed as possible alternatives to simple, unenhanced axial CT of the brain parenchyma. While CT traditionally has afforded the ability to image the brain parenchyma along with the potential to examine the vasculature and blood flow (26, 27), MR imaging has been viewed as particularly appealing owing to the high sensitivity of diffusion-weighted imaging to the early changes of cytotoxic edema in addition to the capacity to delineate vascular anatomy and physiology (8, 9, 12, 25, 28–30).

As thrombolysis is the only proved therapy for acute stroke, but is associated with an increased risk of intracranial hemorrhage, the exclusion of an underlying hemorrhage remains paramount. Owing to the multiplicity of available MR techniques as well as the evolutionary MR appearance of blood products at various field strengths, the sensitivity of MR imaging to hemorrhage has never had the same simple black/white distinction (literally) that has characterized CT. Recent retrospective clinical reports have suggested that carefully performed MR examinations may possess the necessary sensitivity to parenchymal hemorrhage to allow its expeditious, and exclusive, use in the evaluation of acute cerebrovascular events (11, 13). Recent reports indicate that the signal-intensity pattern is consistent with magnetic susceptibility effects of paramagnetic deoxygenated hemoglobin within intact erythrocytes (31).

The results of the present study show that MR imaging can show acute parenchymal hemorrhage and SAH with a high degree of sensitivity in an in vivo model in the time frame presently considered effectual for acute stroke intervention. FLAIR images improve the conspicuity of the SAH lesion on MR images and, along with SD-weighted SE images, help to establish the hemorrhagic nature of the lesion. For parenchymal hemorrhage, detection and diagnosis is best with T2*-weighted GRE images. Additional optimization of FLAIR sequences, to reduce CSF flow artifacts, and implementation of volume GRE imaging, with its improved spatial coverage, may improve this sensitivity.

In this study, the sensitivity of a tailored MR examination to parenchymal hemorrhage appears to be at least comparable to that provided by CT within the first few hours after ictus. Clearly, as the European Cooperative Acute Stroke Study demonstrated, the inability to diagnose completed ischemic infarction accurately may impact patient outcome, as might the catastrophic misdiagnosis of the far less common parenchymal hemorrhage in a patient treated with thrombolytics (1, 2).

Somewhat unexpected were the results of the MR and CT studies performed in subjects with SAH. In retrospect, these results are not surprising, and may reflect interpretive bias relative to MR imaging and limitations in the design of the animal model relative to CT. In particular, prior to this study, CT was (and has remained) the imaging examination of choice for acute cerebrovascular events at our institution, in large part because of our active participation in prospective stroke treatment protocols, which dictate the screening examination (10). The lack of experience with routine clinical MR examination of acute SAH may have played a role in what appears to be the overzealous interpretation of the baseline MR images. Additionally, the model consisted of injecting a relatively small amount (2 mL) of autologous blood into a small subarachnoid space surrounded by the dense bone of the canine posterior fossa. These conditions are remote from clinical practice and, when coupled with the presence of beam-hardening artifacts, become unfavorable to the diagnostic capabilities of CT. In practice, the extent of bleeding necessary to produce a clinical picture of stroke consistent with either SAH or bland infarction (ie, a higher Hunt-Hess grade or a total neurologic deficit of less than 4 on the National Institute of Health Stroke Scale) is unlikely to be ignored by either technique on the basis of tissue contrast and such secondary signs as mass effect and hydrocephalus.

Conclusion

In the setting of significant time constraints, the potential of future therapies in the form of alternative routes of administration (10) and neuroprotective agents (24, 32–34) will require more objective diagnostic data in order to guide therapy rationally (35). MR imaging alone, with appropriately selected sequences, appears able to provide the requisite information for the initiation of treatment.
